PLEASE NOTE
Set images are examples of possible furniture solutions. The dimensions refer to wall beds with full-height frame partitions and h.16,5 cm front top panel.
Structure
Side panel: with frame partitions, full-height, 3 or 5 cm thick.
Top panel: 5 cm thick.
Bed base and Mattresses
Bed base: safety system that prevents the murphy bed from accidentally opening, Inox Blonde finish. Max. bed load: 200 kg.
Mattress: 160x200 h.18/20 cm (max. thickness) / Max. weight: 33 kg. Models selection:
- Premium: h.20 pocket sprung mattress with 11x30 cm springs (single bed) Ø 0,2 cm, Box system with 700 individual pocket springs (double bed) and 7-zoned support system. Internal felt 700 g/sq m, 2 cm D 25 polyurethane foam per side. Winter side with 1 cm memory foam WE 45 density, summer side with 1 cm Watercel 30 E density. Edge supports 25 E density. Amicor removable hypoallergenic cover. This mattress is not suitable for vertical murphy beds with upholstered headboard.
- Elite: pocket sprung mattress with 11x30 cm springs (single bed) Ø 0,2 cm, Box system with 700 individual pocket springs (double bed) and 7-zoned support system. Internal felt 700 g/sq m. Winter side with 1 cm Watercel 30 E density. Edge supports 25 E density. Ecotton hypoallergenic and dust mite-proof padding, Amicor removable hypoallergenic cover, Cotton Plus non-removable cover with aerators.
Equipment
Table: 138x80 cm, 1,8 cm thick, fold-down top fixed on the front panel, legs in Inox Blonde finish. Max. load: 30 kg.
Headboard: for d.32,8 cm bed, upholstered cushion fixed on the back panel, cat. A or B fabrics, non-removable cover.
Optionals
LED lighting: recessed, w.28 cm, supplied with switch and 5W / 12V power supply, placed on the right side panel. No. 2 elements for 160 cm wall beds.
Sockets and flush switch: no. 2 10-16A / 250V power sockets, 16A / 220V switch, only available for d.45,6 and 58,4 cm wall beds, placed on the side panels.
Upholstered headboard: h.42 cm cushion for d.32,8 cm wall beds back panels, cat. A or B fabrics, non-removable.
Internal shelves:
- with front panel: w.169,9 d.12,8 h.9,8 cm, 3 cm thick, for d.45,6 and 58,4 cm wall beds
- without front panel: w.169,9 d.12,2 cm, 3 cm thick, for d.45,6 and 58,4 cm wall beds / d.25 cm for d.58,4 cm wall beds
Assembly
The murphy bed is disassembled and comes with assembly instructions. Wall fixation with supplied brackets is required. Anchoring on plasterboard walls doesn't guarantee tightness.
